Single & Double Cabinet HFC-227ea Fire Suppression System
The Cabinet Type HFC-227ea Fire Extinguishing System is an advanced, clean agent fire suppression system that excels in protecting precision equipment and vital facilities. This system is celebrated for its safety, efficiency, and eco-friendly attributes, leaving no residue after activation.
Eliminates the necessity for a separate cylinder room.
Standalone system guarantees effortless installation.
Effectively combats A, B, and C class fires.
Single Cabinet Type
| Model | Dimensions (mm) | Agent Weight (kg) | Protection Vol (m³) | Ext. Conc. | Temp. | Actuation | Pressure |
|---|---|---|---|---|---|---|---|
| GQQ40/1.2-5.2Y | 500×450×1200 | 0-44.8 | ≤58 | 6.0-8.0% | 0-50°C | Auto / Manual | 2.5MPa |
| GQQ70/1.2-5.2Y | 500×450×1400 | 0-74.8 | ≤102 | ||||
| GQQ120/1.2-5.2Y | 500×450×1700 | 0-112.9 | ≤145 | ||||
| GQQ210/1.2-5.2Y | 500×500×2100 | 0-186.9 | ≤262 |
Double Cabinet Type
| Model | Dimensions (mm) | Agent Weight (kg) | Protection Vol (m³) | Ext. Conc. | Temp. | Actuation | Pressure |
|---|---|---|---|---|---|---|---|
| GQQ40×2/2.5-ZY | 980×450×1200 | 0-89.6 | ≤116 | ~6.0-8.0% | 0-50°C | Auto / Manual | 2.5MPa |
| GQQ90×2/2.5-ZY | 980×450×1700 | 0-201.6 | ≤262 | ||||
| GQQ150×2/2.5-ZY | 980×500×1950 | 0-276.9 | ≤363 | ||||
| GQQ210×2/2.5-ZY | 980×500×2100 | 0-373.8 | ≤504 |
Our facility integrates research, development, design, manufacturing, and engineering. We utilize advanced testing apparatus in modern workshops to ensure the highest quality standards. With a focus on innovative fire extinguishing technology, we provide reliable fire protection solutions for diverse industrial sectors.
