High-Tolerance Stamped Bullet Connectors: Phos-Bronze Pin & Socket Crimp Terminals

1 / 5

High-Tolerance Stamped Bullet Connectors: Phos-Bronze Pin & Socket Crimp Terminals

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Specifications

Model NO.

1393365-1

Processing Type

Shaping Metal

Material

Free-Cutting Brass (C3604)

Mould

Multistep Progressive Dies

Surface Processing

Nickel Barrier + Matte Tin

Tolerance

±0.02mm

Current Rating

20A-100A

Voltage Rating

48V DC

Compliance

Uscar-2, LV214, RoHS, Reach

Capacity

1,000,000 / Day

Dual-Material Terminal System

Engineered with brass bodies for superior conductivity and phosphor bronze springs for unmatched contact resilience, our bullet terminals are designed to solve vibration-induced failures in automotive power distribution systems. These components exceed 100 mating cycles at 150°C, making them ideal for engine bay and EV battery applications.

Parameter	Male Terminal	Female Terminal	Test Standard
Wire Range	1.0-16mm² (18-6 AWG)	0.5-10mm² (20-8 AWG)	ISO 19642
Contact Resistance	≤1.8mΩ	≤2.0mΩ	USCAR-2 Sec 5.3
Insertion Force	≤15N	≤25N	LV214
Retention Force	≥50N	≥45N	USCAR-21
Mating Cycles	100+	100+	GMW3191
Salt Spray	240hrs	240hrs	ASTM B117

High-Tolerance Stamped Bullet Connectors

Phos-Bronze Pin & Socket Crimp Terminals

Key Advantages

💎Optimized Material Pairing

Brass Body (C3604): 28% IACS conductivity, cold-forged for high strength.
Phos-Copper Contacts (C5191): 80,000psi tensile strength with 100% elastic recovery.

🛡️Anti-Vibration & Corrosion Defense

Dual-beam contact design with hyperbolic curve for stable connection.
Nickel barrier layer prevents zinc migration and ensures longevity.
Tin plating with anti-fretting additives for harsh environment protection.

⚡Technical Superiority

35% higher ampacity compared to standard pure brass terminals.
Heat dissipation fins integrated into male terminals for thermal management.
500 thermal shock cycles validation (-40°C to 150°C).

Dimensional Matrix

Terminal Size	Bullet Ø (mm)	Current Rating	Wire Range (mm²)
Small	Ø3.0	20A	0.5-1.5
Medium	Ø4.8	40A	2.5-6.0
Large	Ø6.3	70A	6.0-10.0
X-Large	Ø8.0	100A	10.0-16.0

Quality Assurance & Manufacturing

Certifications
IATF 16949 Certified Production, UL 486E Recognized Component.

Testing Protocols
Micro-section Crimp Analysis & 3000hrs Thermal Aging at 150°C.

Our facility was founded in 1991, covering 100,000 square meters. we provide comprehensive stamping line solutions including press machine manufacturing and precision metal parts for mobile phones, electronics, and new energy battery fields.

Frequently Asked Questions

Q1: What materials are used for the terminal construction?

We use a hybrid construction consisting of a Brass (C3604) body for high conductivity and Phosphor Copper (C5191) contacts for superior tensile strength and elastic recovery.

Q2: How do these terminals perform in high-vibration environments?

The terminals feature a dual-beam contact design with a hyperbolic curve and strain relief crimp wings, validated to withstand 30m/s² vibration at 10-2000Hz.

Q3: What is the maximum temperature these connectors can withstand?

Our bullet terminals are designed for harsh automotive environments, exceeding 100 mating cycles at 150°C and surviving 3000 hours of thermal aging.

Q4: Are your products compliant with international automotive standards?

Yes, our terminals comply with USCAR-2, LV214, RoHS, and Reach standards, and our production is IATF 16949 certified.

Q5: What is the daily production capacity for these stamping parts?

We have a massive production capability of up to 1,000,000 pieces per day, supported by high-precision progressive die stamping.

Q6: Do you provide documentation for quality traceability?

Yes, we provide PPAP Level 4 documentation, batch-specific salt spray reports, and laser-etched QR codes for full traceability on every terminal.
