Mxr75040L 30kw@750V Liquid Cooling EV Charging Module with High Efficiency Power

Customization:	Available
Type:	Fast EV Charging Station
Weight:	<25kg

Basic Information

Model NO.	MXR75040L
Cooling Method	Liquid Cooling
Rated Output Power	30kw
Communication	Can Bus
Parallel Quantity	<60 Pieces
Rated Output Current	91A
Output Voltage Range	200-750VDC
Current Limit Adjustable	10-110% Stepless Adjustable
Certification	CE, ISO, TUV, RoHS
Warranty	12 Months
Transport Package	Wooden, Carton
Specification	37073520

Product Description

MXR75040L is a high-performance charging power module developed specifically for the evolving requirements of the charging infrastructure industry. It features prominent advantages in two critical areas: ultra-high full-load operating temperature and an ultra-wide constant power range.

Key characteristics include high reliability, superior efficiency, high power factor, and high power density. With a wide output voltage range, low noise levels, and low standby power consumption, this module provides excellent EMC performance for modern EV charging solutions.

Technical Parameters

Input Characteristics

Item	Parameters
Rated Input Voltage	380Vac/480Vac, three-phase
Input Voltage Range	530-320Vac (full load)
Input Current	<63A
Grid Frequency	45Hz-65Hz
Power Factor	≥0.99
ITHD	≤5%

Output Characteristics

Item	Parameters
Output Power	30kw
Peak-to-peak Noise	≤±0.5%
Voltage Accuracy	≤±0.5%
Current Accuracy	≤±1%
Effectiveness	≥94.5%

Detailed Photos

Certifications

Packaging & Shipping

Industry Presence

As a state-level high-tech enterprise, we focus on the research, development, and production of power electronic products. Our services are positioned for mid-to-high-end DC power supply system manufacturers. With independent intellectual property rights and a commitment to technological innovation, we provide professional equipment and services to global clients.

Since our establishment, we have built a high-quality R&D team serving as practitioners of technological innovation in the power supply industry. Our products are widely used in automotive, electric power, railway, communications, and other specialized fields across the globe.

Frequently Asked Questions

1. What makes your EV Charger Modules stand out in the industry? Our professional technical team ensures a leading industry position. We offer international standardization designs, smart back-end services, and modules that have passed rigorous application scenarios and laboratory standard tests.

2. What are the core technical advantages of the DC charging modules? Advantages include digital controlled power, active PFC achieving 0.99 power factor, soft start functions, and comprehensive protection for both input (over/under voltage, surge) and DC output (over-current, short-circuit).

3. Which charging standards are your products compatible with? Our solutions comply with global standards including CCS-1 (North America), CCS-2 (Europe), CHAdeMO (Japan), and GB/T (China) standards.

4. How is after-sales support handled for international customers? We provide comprehensive technical training through written materials and videos. For urgent situations, we master parts replacement and maintenance guidance, and can provide professional technician support when required.

5. What are your standard terms for packing and delivery? Generally, goods are packed in kraft cartons with pallets. Delivery is typically made within 2-3 weeks after order confirmation, with payment terms usually being T/T in advance or Irrevocable L/C at sight.
